Description
MSI B850 GAMING PLUS WIFI, AM5, 4x DDR5 256GB, 1x HDMI, 4x PCI-E x16 slot, 3x M.2, Wi-Fi 7
Chipset
AMD X840
CPU
Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Memory
4x DDR5 UDIMM, Maximum Memory Capacity 256GB
Onboard Graphics
1x HDMI™
Support HDMI™ 2.1 FRL, maximum resolution of 8K 60Hz*
1x Type-C DisplayPort
USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz*
Slot
4x PCI-E x16 slot
Audio
Realtek® ALC897
7.1-Channel High Definition Audio
Storage
3x M.2
RAID
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
LAN
Realtek® 8126-CG 5G LAN
WIRELESS LAN & BLUETOOTH
Wi-Fi 7
Supports Bluetooth® 5.4**, MLO, 4KQAM
LED FEATURE
4x EZ Debug LED
OPERATING SYSTEM
Support for Windows® 11 64-bit
Specifications
| Manufacturer's Code | MBM-B850GAMINGPLUSWIFI |
|---|---|
| Product Category | Motherboards |
